Product image for Square D 9007AP325 600 VAC 15 Amp 1NO 1NC Cast Zinc Heavy Duty Industrial Snap Switch
Image thumbnail 0
Image thumbnail 1
Email

Square D 9007AP325 600 VAC 15 Amp 1NO 1NC Cast Zinc Heavy Duty Industrial Snap Switch

Manufacturer: Square-D / Schneider | Catalog # 9007AP325 | Echo Electric Part # 177465
$150.63/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page
SNAP SWITCH 600VAC 15AMP AP +OPTIONS

Technical Information

Action
LINEAR,SNAP ACTION
Actuator
CAST ZINC,PLUNGER HEAD,SPRING RETURN CROSS ROLLER PLUNGER STEEL BUSHING MOUNTED,TRAVERSE APPROACH, 2 DIRECTIONS
Amperage
15 Amp,5 Amp 600 V AC, A600 NEMA RATING DESIGNATION-6 Amp 480 V AC, A600 NEMA RATING DESIGNATION-10 Amp 240 V AC, A600 NEMA RATING DESIGNATION-15 Amp 120 V AC, A600 NEMA RATING DESIGNATION-0.02 Amp 600 V DC-0.2 Amp 250 V DC-0.5 Amp 125 V DC
Contact Configuration
FORM Z,NC-NO SPDT-DB
Contact Material
Silver
Enclosure
NEMA 1 NEMA TYPE 250
Material
Metal
Mounting Type
Panel Mounting Oil Tight
Number of Poles
1 Pole
Number of Steps
1
Operating Temperature
-20-185 Adegrees F
Size
0.83 IN,2.5 IN,2.69 IN
TC Connection
1-2 6 BINDER HEAD SCREW TERMINALS AWG 22...AWG 14)
Type
SNAP LIMIT SWITCH

Manufacturer Information

Brand
Square D
Sub Brand
9007AO/CO

General Product Info

12-Digit UPC
785901126379
GTiN
00785901126379
Product UPC
78590112637
Weight
0.1 lb

Dimensions

Depth
2.69 Inch
Height
2-1/2 Inch
Warranty Length
18 mth
Width
0.83 in

Certifications and Compliance

CA Prop65 Warning
This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP) and Diisononyl phthalate (DINP) which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.gov
Country of Origin
Mexico
