TESENSOR - TES Sensors 9007AP321 Snap switch, 9007AO, metal roller plunger head, 15A at 120VAC, 1NO/1NC, open type

Essential specifications

12-Digit UPC - 785901809418
Actuator - Cast zinc;Plunger head
Amperage - 15 Amp,5 Amp 600 V AC, A600 NEMA RATING DESIGNATION-6 Amp 480 V AC, A600 NEMA RATING DESIGNATION-10 Amp 240 V AC, A600 NEMA RATING DESIGNATION-15 Amp 120 V AC, A600 NEMA RATING DESIGNATION-0.02 Amp 600 V DC-0.2 Amp 250 V DC-0.5 Amp 125 V DC
Catalog Number - 9007AP321
Depths - 2.69 Inch

Packaging

1 ea

EAN

00785901809418

Part #

163220

Catalog #

9007AP321

Commercial reference

9007AP321

12-Digit UPC:

785901809418

Actuator:

Cast zinc;Plunger head

Amperage:

15 Amp,5 Amp 600 V AC, A600 NEMA RATING DESIGNATION-6 Amp 480 V AC, A600 NEMA RATING DESIGNATION-10 Amp 240 V AC, A600 NEMA RATING DESIGNATION-15 Amp 120 V AC, A600 NEMA RATING DESIGNATION-0.02 Amp 600 V DC-0.2 Amp 250 V DC-0.5 Amp 125 V DC

Catalog Number:

9007AP321

Depths:

2.69 Inch

ERP_productname:

TES 9007AP321 SNAP SWITCH 600VAC 15AMP AP +OPTIONS

Enclosure:

NEMA 1 NEMA TYPE 250

Family Brand Name:

Telemecanique

Heights:

2-1/2 Inch

Material:

Metal

Mounting Type:

Panel Mounting Non-oil Tight

Number of Poles:

1 Pole

Size:

2.69 in

Sub Brand:

9007AO/CO

Tc Connection:

1-2 6 BINDER HEAD SCREW TERMINALS AWG 22...AWG 14)

Type:

Snap limit switch

Voltage:

600 Volt

Widths:

0.83 in

SoneparProductId:

SKU_US_26904387

Industrial snap switches are used as the electrical contacts within many control circuits and products. This snap switch has a steel bushing mounted roller plunger. This snap switch has one normally open and one normally closed snap action contacts. Contacts have an A600 inductive rating and 15A resistive rating. They also have 15A at 125VAC, 10A at 240VAC, 6A at 480VAC and 5A at 600VAC ratings. They also have 0.5A at 125VDC, 0.2A at 250VDC and 0.2A at 600VDC ratings. This snap switch is 2.50 inches tall, 0.83 inches wide and 2.69 inches deep. Snap switch is NEMA 1 and IP20 rated. Snap switch is UL component recognized and CSA certified. It supports non oil tight panel mounting. The 9007 series limit switches are designed to withstand harsh industrial environments and are available in a wide range of options.
