Mersen AJT250/600 Reducer Fuse AJT

Manufacturer: Ferraz Shawmut | Catalog # AJT250/600 | Echo Electric Part # 193650
$641.10/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet
AJT Reducer Fuses are a safe permanent solution for decreasing your current rating without using a fuse reducer which are designed and list for temporary use only. These reducer fuses provide the same trusted protection levels as a traditional AJT fuses but in a larger body.

Technical Information

Fuse Class
Class J
Insulation Material
GMG
Mounting Type
Bolted,Clip
Rated Voltage AC
600 V
Rated Voltage DC
500 V
Terminal Material
Brass
Terminal Type
Blade

Manufacturer Information

Brand
Ferraz Shawmut Canada, Inc.

General Product Info

12-Digit UPC
782001463885
GTiN
00782001463885
Product UPC
78200146388
Weight
3.25 lb

Dimensions

Diameter
2-1/2 Inch
Length
8 Inch
Features
  • Replaces traditional temporary-use only Fuse Reducer accessories
  • Recommended for Arc Flash energy reduction
  • Extremely current-limiting for low peak let-thru current
  • Most current-limiting UL class fuse
  • Time-delay for motor starting and transformer inrush
  • High-visibility orange label gives instant brand recognition
  • Metal-embossed date and catalog number for traceability and lasting identification
  • Fiberglass body provides dimensional stability in harsh industrial settings
  • High-grade silica filler ensures fast arc quenching
  • Optional EI indicator/switch
Applications
  • Motor circuits
  • Mains
  • Feeders
  • Branch circuits
  • Lighting, heating & general loads
  • Transformers
  • Control panels
  • Circuit breaker back-up
  • Bus duct
  • Load centers
Approvals & Standards
  • UL Listed to standard 248-8 File E2137
  • IEC 269-2-1
