Product image for Panduit DNH14-250FIM-Q 0.25 Inch 16 to 14 AWG Heat Shrink Fully Insulated Male Disconnect
Email

Panduit DNH14-250FIM-Q 0.25 Inch 16 to 14 AWG Heat Shrink Fully Insulated Male Disconnect

Manufacturer: Panduit Corp | Catalog # DNH14-250FIM-Q | Echo Electric Part # 109738
$450.22/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Buy American Compliant Buy American Compliant Product Spec Sheet Product Catalog Page
The male tab disconnect is made of brass and is nickel-plated. It is fully insulated in blue heat shrink. It has a tab size of 0.250 x 0.032 (6.3 x 0.8 mm) and supports a wire range of 16-14 AWG (1.5-2.6 mm²). It is 1.5" (38.1 mm) long and 0.41" (10.4 mm) wide. The disconnect has a standard barrel configuration and a sleeved barrel. It comes in bags of 25.

Technical Information

Barrel Type
Sleeved Barrel
Conductor Size
14 AWG
Material
Brass
Max Operating Temperature
110 degrees C
TC Connection
Standard
Temperature Rating
230 F
Type
Disconnect
Voltage
600 Volt
Wire Size
16-14 AWG

Packaging

Pkg Qty
25

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Pan-Term®

General Product Info

12-Digit UPC
074983818280
Color
Blue
Finish
Nickel
GTiN
00074983818280
Product UPC
07498381828
UNSPSC
39121409

Dimensions

Depth
0.9 Inch
Height
0.31 Inch
Overall Length
1.5 in
Width
0.41 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
