Product image for PHNX 1823638 SPT-THR 1 5/ 2-H-3 5 P20 R24
Email

PHNX 1823638 SPT-THR 1 5/ 2-H-3 5 P20 R24

Manufacturer: Phoenix Blocks | Catalog # 1823638 | Echo Electric Part # 115980
$2.65/ea
ea
Order in multiples of 250 (pack qty)
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
PCB terminal block, nominal current: 13.5 A, rated voltage (III/2): 160 V, nominal cross section: 1.5 mm², number of potentials: 2, number of rows: 1, number of positions per row: 2, product range: SPT 1,5/..-H-THR, pitch: 3.5 mm, connection method: Push-in spring connection, mounting: THR soldering, conductor/PCB connection direction: 0 °, color: black, Pin layout: Linear double pinning, Solder pin [P]: 2 mm, number of solder pins per potential: 2, type of packaging: 24 mm wide tape

Technical Information

Current
13.5 Amp
Mounting Type
THR Soldering
Number of Connections
2
Number of Rows
1
Strip Length
8 mm

Manufacturer Information

Brand
Phoenix Contact

General Product Info

12-Digit UPC
463568142870
Product UPC
46356814287

Dimensions

Height
9.7 mm
Length
13.6 mm
Width
7.5 mm
Features
  • Time saving push-in connection, tools not required
  • Defined contact force ensures that contact remains stable over the long term
  • Intuitive use through colour coded actuation lever
  • Designed for integration into the SMT soldering process
  • Quick and convenient testing using integrated test option
  • Operation and conductor connection from one direction enable integration into front of device
  • Two solder pins reduce the mechanical strain on the soldering spots
Approvals
  • VDE Zeichengenehmigung
  • EAC
  • IECEE CB Scheme
  • cULus Recognized
