Product image for Hoffman Q1PBPCDM 75 x 73 x 79mm QLINE-D 22.5mm Pushbutton Enclosure, Polycarbonate
Email

Hoffman Q1PBPCDM 75 x 73 x 79mm QLINE-D 22.5mm Pushbutton Enclosure, Polycarbonate

Manufacturer: nVent Hoffman | Catalog # Q1PBPCDM | Echo Electric Part # 138984
$84.54/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet
Used for insulating and housing 30.5-mm or 22.5-mm pushbuttons in hostile environments, QLine D Enclosures have contoured bodies with flush cover screws for an attractive, contemporary appearance.

Technical Information

Applications
Controls and Drives; Corrosive Environments
Color Coding
RAL 7035
Cover Type
Screw
IP Rating
66
Material
Polycarbonate
Size
3.23 x 3.15 in
Standard
12,13,4X,CSA File Number 42186: Type 4,CUL Listed Per CSA C22.2 No 94,Enclosure Flammability Evaluated Per UL 508A,IEC 60529,IP67,NEMA/EEMAC Type 4,No. E61997,Type 4,UL 508A Listed
Type
1 Hole

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
Qline™ D

General Product Info

12-Digit UPC
783510150990
Color
Gray
Finish
Smooth
GTiN
00783510150990
Product UPC
78351015099
Used With
22.5 mm Pushbutton
Weight
0.3 lb

Dimensions

Depth
79 mm
Height
75 mm
Length
3.1 Inch
Thickness
3 mm
Width
73 mm
Features
  • High-impact polycarbonate material is used for both body and cover
  • Polycarbonate material is easily punched, drilled, filed or sawed
  • Straight side walls permit ganging of multiple enclosures
  • Cross-point captivated cover screws are stainless steel
  • Mounting holes molded directly adjacent to cover screws
  • Cover screws protected by removable caps that are both aesthetic and provide tamper resistance
  • Molded internal pads for mounting optional panels, rails or other components
  • Seamless foam-in-place gasket assures watertight and dust-tight seal
  • Screws provided for mounting optional panel
  • Optional panels are unpainted plated steel
  • Mounting hardware furnished
  • Material is halogen free
