Hubbell SE2720A 30 Amp 240 Volt NEMA L15-30R Switched Enclosure with Receptacle

Manufacturer: Hubbell Wiring Device | Catalog # SE2720A | Echo Electric Part # 155795
$557.25/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet Product Catalog Page Installation / Instruction Manual
Switches and Lighting Controls, Industrial Grade, Lever Actuated, Switched Twist-Lock Enclosure With pre-wired HBL2720 Receptacle, 30A Twist-Lock®, 3 Phase 240 V AC, NEMA L15-30R, Terminal Screws, Gray.

Technical Information

Action
Snap
Actuator
Lever
Amperage
30A Max Amp
Applications
Extra Heavy Duty Industrial
Base Material
PBT
Contact Configuration
Two Position
Contact Rating
30A
Enclosure
Non-Metallic
Horsepower
3 hp
Material
Composite
Mounting Type
Feet
NEMA
L15-30R
Number of Poles
3 Pole
Number of Wires
4 Wire
Operating Cycles
6000
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
12K Enclosure Rating,CSA,Type 3R,UL Standard
Temperature Rating
-40 to 67 degrees C
Type
Switched Enclosure With Receptacle
Voltage
240 Volt
Wattage
7200 Watt

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Circuit-Lock

General Product Info

12-Digit UPC
783585006451
Color
Gray
Environmental Conditions
NEMA 4X
GTiN
00783585006451
Product UPC
78358500645
Weight
4.05 lb

Dimensions

Height
4.38 Inch
Length
11.38 Inch
Width
4.88 in

Certifications and Compliance

Country of Origin
USA
Features
  • Lockable handle provides lockout protection for greater safety and complies with OSHA lockout requirements
  • Horsepower rated switch
  • Large receptacle gasketless door and hinge assembly
  • Heavy-duty internal frame bonds conduit and all grounds and has a DIN rail to accommodate the switch
