Product image for Hubbell HBL3767 Locking Flanged INLT, 50A 250VDC/600VAC, 2P3W, COV
Image thumbnail 0
Image thumbnail 1
Email

Hubbell HBL3767 Locking Flanged INLT, 50A 250VDC/600VAC, 2P3W, COV

Manufacturer: Hubbell Wiring Device | Catalog # HBL3767 | Echo Electric Part # 163110
$315.72/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Twist-Lock®, Industrial, Flanged Inlet, 50A 250V AC/600V AC, 2-Pole 3-Wire Grounding, Non-NEMA, Screw Terminal, Zinc plated steel casing, thermoset interior with lift cover, Metallic

Technical Information

Amperage
50 Amp
Applications
Extra Heavy Duty Industrial
Conductor Size
8-4 AWG
Current
50 Amp
Dielectric Strength
2000 V
Grounding
Grounding
Material
Steel
Mounting Type
Screw
Number of Phases
3 Phase
Number of Poles
2 Pole
Number of Wires
2 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA C22.2 No.42,UL 498
TC Connection
Pressure Screw Terminals
Temperature Rating
-40 to 75 degrees C
Type
Standard Single
Voltage
250 Volt
Wattage
30000 Watt
Wire Count
3
Wire Size
8-4 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585236445
Color
Metallic
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
GTiN
00783585236445
Product UPC
78358523644
Weight
1.05 lb

Dimensions

Height
2.56 Inch
Length
2.17 Inch
Width
3.50 in

Certifications and Compliance

Country of Origin
Puerto Rico
Features
  • Metallic flanged casing provides maximum strength and protection
  • Thermoset interior provides superior heat resistance
  • With Lift Cover
