Product image for TES Sensors 9007AP321 Snap switch, 9007AO, metal roller plunger head, 15A at 120VAC, 1NO/1NC, open type
Email

TES Sensors 9007AP321 Snap switch, 9007AO, metal roller plunger head, 15A at 120VAC, 1NO/1NC, open type

Manufacturer: TES ELECTRIC | Catalog # 9007AP321 | Echo Electric Part # 163220
$190.90/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
Industrial snap switches are used as the electrical contacts within many control circuits and products. This snap switch has a steel bushing mounted roller plunger. This snap switch has one normally open and one normally closed snap action contacts. Contacts have an A600 inductive rating and 15A resistive rating. They also have 15A at 125VAC, 10A at 240VAC, 6A at 480VAC and 5A at 600VAC ratings. They also have 0.5A at 125VDC, 0.2A at 250VDC and 0.2A at 600VDC ratings. This snap switch is 2.50 inches tall, 0.83 inches wide and 2.69 inches deep. Snap switch is NEMA 1 and IP20 rated. Snap switch is UL component recognized and CSA certified. It supports non oil tight panel mounting. The 9007 series limit switches are designed to withstand harsh industrial environments and are available in a wide range of options.

Technical Information

Action
Snap action;Linear
Actuator
Cast zinc;Plunger head
Amperage
15 Amp,5 Amp 600 V AC, A600 NEMA RATING DESIGNATION-6 Amp 480 V AC, A600 NEMA RATING DESIGNATION-10 Amp 240 V AC, A600 NEMA RATING DESIGNATION-15 Amp 120 V AC, A600 NEMA RATING DESIGNATION-0.02 Amp 600 V DC-0.2 Amp 250 V DC-0.5 Amp 125 V DC
Body Material
Cast Zinc
Body Type
Fixed NULL
Contact Configuration
Form Z
Contact Material
Silver
Enclosure
NEMA 1 NEMA TYPE 250
Material
Metal
Mounting Type
Panel Mounting Non-oil Tight
Net Weight
0.1 lb
Number of Poles
1 Pole
Number of Steps
1
Operating Temperature
-20-185 Adegrees F
Size
2.69 in
Storage Temperature
-20-185 degrees F
TC Connection
1-2 6 BINDER HEAD SCREW TERMINALS AWG 22...AWG 14)
Type
Snap limit switch
Voltage
600 Volt

Manufacturer Information

Brand
Telemecanique
Sub Brand
9007AO/CO

General Product Info

12-Digit UPC
785901809418
GTiN
00785901809418
Product UPC
78590180941

Dimensions

Depth
2.69 Inch
Height
2-1/2 Inch
Warranty Length
18 mth
Width
0.83 in
