Eriflex 563400 MBJ Grounding and Bonding Braid, Tinned Copper, 250 A Ampacity, 98.68 kcmil, 11.811", 0.728" Hole

Manufacturer: Erico, Inc | Catalog # 563400 | Echo Electric Part # 165687
$28.40/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet Product Catalog Page
Flat Tinned Copper Grounding Braid. MBJ50-300-18, 250 A Ampacity, 98.68 kcmil (50 mm²), 11.811" (300 mm), 0.728" (18.5 mm) Hole.

Technical Information

Applications
Grounding and Bonding; Power Connections
Material
Copper
Type
Grounding and Bonding Braids

Manufacturer Information

Brand
nVent Eriflex
Sub Brand
ERIFLEX

General Product Info

12-Digit UPC
782856579588
Finish
Tinned
GTiN
00782856579588
Product UPC
78285657958
Weight
0.17 kg

Dimensions

Hole Size
18.5-18.5
Length
300-300
Thickness
2.5-2.5
Features
  • Complete range of earth/ground flexible connections from 6 - 100 mm² (11.84 - 197.35 kcmil) cross section and from 100 - 500 mm (3.937\" - 19.685\") length
  • Integral palm, without tin or crimped lugs for superior electrical contact and tensile strength resistance
  • Resistant to vibration and fatigue, reducing maintenance
  • Provides weight savings, material savings and lower impedance when compared to similar lugged cables with insulation
  • Ready to use out of the box, eliminates the need for cutting, stripping, crimping and punching
  • Quick and easy to install
  • Recommended by the EMC/EMI directives and less impedance than cables
  • EAC compliant
  • RoHS compliant
  • Compliant to ISO 6469-1 (Electrically propelled road vehicles - Part 1: Rechargeable energy storage system) - Section 6.2.2 Vibrations
Certifications
  • UKCA, ERIFLEX MBJ EN 61439-1
  • cUL CSA C22.2 No. 41
  • UL ANSI/UL 467
