Product image for HWDK GFBFHP20I 20A 125V BLANK FACE
Email

HWDK GFBFHP20I 20A 125V BLANK FACE

Manufacturer: Hubbell Wiring Device | Catalog # GFBFHP20I | Echo Electric Part # 169853
$44.19/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet Product Catalog Page Installation / Instruction Manual
Power Protection Products, GFCI,Receptacle, Blank Face, 20A 125V, HP Rated, Ivory

Technical Information

Amperage
20 Amp
Applications
GFCI Protection
Conductor Size
14-12 AWG
Current
20 Amp
Dielectric Strength
1500 volts between (line H to load H), (line H to face H), (line N to load N) and (line N to face N)
Material
Composite
Number of Wires
3 Wire
Size
Standard Sized Product
Style
1.5HP,Blank Face
TC Connection
Terminal Screws
Temperature Rating
-40 Degrees C to 75 Degrees C
Type
Standard
Voltage
125 Volt
Wattage
2500 Watt
Wire Size
14-12 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Ground Fault Receptacle

General Product Info

12-Digit UPC
883778450044
Color
Ivory
Environmental Conditions
Dry Indoors unless Protected by Additional Means
GTiN
00883778450044
Product Series
Heavy Duty
Product UPC
88377845004

Dimensions

Height
4.6 Inch
Length
4-1/4 Inch
Width
3.1 in

Certifications and Compliance

Country of Origin
China
Features
  • Blank face 1.5 horsepower motor control rated switch UL508 listed. Also listed to Underwriters Laboratories standard 943 for Class A GFCI
  • If wired incorrectly there will be no power to the face or to downstream receptacles for added safety. (2) LED indicators provide immediate status of power, trip condition and ability to provide GFCI protection
  • In addition to providing Class A GFCI protection, the HP series includes a 1.5 HP rating for motor control switching per UL508
