Pass & Seymour PS30-SSAX Non-Fusible Safety Switch w/ Auxillary Contact, 30A 600 VAC

Manufacturer: Pass & Seymour / Legrand | Catalog # PS30-SSAX | Echo Electric Part # 173307
$539.15/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Buy American Compliant Buy American Compliant Product Spec Sheet Safety Data Sheet
Non-Fusible Safety Switch with Auxiliary Contact, 30 Amps, 600 VAC. The first non-metallic NEMA 4X Non-Fusible Safety Switch line UL Listed as Suitable as Motor Disconnect per NEC Article 430.109(A)(6). P&S Non-Fusible Safety Switches feature extra-tough components, including an impact-resistant Valox NEMA 4X enclosure. And an innovative design that delivers safe, sure operation under the worst conditions.

Technical Information

Action
Motor Disconnect Switch
Actuator
Toggle
Amperage
30 Amp
Applications
Industrial
Connection Type
Hard Wired
Contact Configuration
15amp/120-277vac
Contact Rating
10 A
Enclosure
NEMA 1
Frequency
60.0 Hz
Material
Valox
Number of Poles
4 Pole
Operating Cycles
10k
Operating Temperature
Maximum continuous: +60degrees C; Minimum continuous: -50degrees C
Size
5.75 L x 4.88 W x 9.69 H In
Standard
ANATEL,CA Energy Commission Title 24,COFETEL,CUL,FCC,IC,SUTEL
TC Connection
Hard Wired
Type
Combination Starter,Non-Fusible Disconnect Switch Type
Voltage
600 Volt

Manufacturer Information

Brand
Pass & Seymour
Sub Brand
Pass & Seymour

General Product Info

12-Digit UPC
785007150032
Color
Gray
Finish
Matte
GTiN
00785007150032
Product UPC
78500715003
UNSPSC
39121403

Dimensions

Depth
4.88 Inch
Height
9.69 Inch
Width
7.38 in

Certifications and Compliance

Buy American Compliant
Y
Certifications
CULUS
Country of Origin
USA
Certifications
  • cULus Listed
Features
  • Compact design fits in most I-beams to provide mounting versatility, easy access, and reduced possibility of impact damage.
  • Nonconductive, watertight, corrosion-, heat-, and impact-resistant thermoplastic enclosure ensures NEMA 4X and 12 ratings. Withstands the harshest industrial environments.
  • Corrosion-resistant, stainless steel captive screws speed installation, minimize risk of lost parts, and withstand abuse.
  • Adjustable mounting feet can be moved to center of unit for instant strut- or pole-mounting without special brackets or harnesses.
  • Durable, stainless steel coverretaining chain makes installation and maintenance more convenient.
  • Heavy-duty, ergonomic switch handle meets OSHA Lockout/Tagout provisions and provides plenty of grip for sure, easy operation.
  • Black/red color coding and high-visibility ON/OFF markings clearly indicate status from a distance and at any visual angle.
  • Switch entry into the enclosure is offset to the side and sealed to provide enhanced water resistance.
  • Bottom and top wiring access options. No unnecessary openings to compromise water resistance.
  • Top mount auxiliary contact enables additional control functions or signal lights.
  • Certified for IP69 applications.
