Pass & Seymour 15W47AM 15A 125V Straight Blade Anti Microbial IP67 5-15R Connector, Orange/Yellow

Manufacturer: Pass & Seymour / Legrand | Catalog # 15W47AM | Echo Electric Part # 174899
$69.62/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Buy American Compliant Buy American Compliant Product Spec Sheet
SteriGuard™ Anti-Microbial Wiring Devices provide excellent protection against the growth of microbes on all surfaces. Independent testing proves the ability of these devices to inhibit the growth of Escherichia coli, Gram (-) and Staphylococcus aureus, Gram (+) providing long lasting benefits to manufacturers’ beyond conventional cleaning methods. Rated watertight for 1,500 psi high-pressure hosedown, these plugs and connectors feature multiple seals to ensure protection against the environment. SteriGuard provides a cost-effective way to add additional safety precautions and unequaled assurance that every feasible step has been taken in the interest of consumer protection. "

Technical Information

Amperage
15 Amp
Applications
Commercial
Conductor Size
18-12 AWG
Connection Type
Cable
Cord Type
S, SO, ST, SJ, SJO, SJT, 18/3, to 12/3, .300" min to .625" max diameter
Grade
Commercial
Material
Thermoplastic
NEMA
5-15R
Number of Poles
2 Pole
Number of Wires
3 Wire
Size
1.81" (Height) x 1.81" (Width) x 4.01 (Depth)
TC Connection
Cable
Temperature Rating
-40 degrees C to 60 degrees C
Type
Anti-Microbial
Voltage
125 Volt
Wire Size
18-12 AWG

Manufacturer Information

Brand
Pass & Seymour
Sub Brand
Pass & Seymour

General Product Info

12-Digit UPC
785007056983
Color
Yellow
Environmental Conditions
-40 to 60 C
GTiN
00785007056983
Product UPC
78500705698
Used With
S, SO, ST, SJ, SJO, SJT, 18/3, to 12/3, 0.3 in minimum to 0.625 in maximum diameter Cord

Dimensions

Diameter
1.81 Inch
Length
4.01 Inch

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
Features
  • UL and CSA Listed
  • NSF (National Sanitation Foundation) Certified
  • Patent Pending
  • Anti-microbial Additives Embedded in polymer and inhibits Growth of Bacteria, Molds, Mildews and Fungi
  • Anti-microbial Additive Resistant to Scuffing and Cleaning
  • Escherichia (E.Coli): - Log reduction > 4.8, reduced surface bacteria by > 99.99%
  • Staphylococcus (Staph), MRSA: - Log Reduction > 4.3, reduces surface bacteria by > 99.97%
  • Salmonella Log Reduction > 3.6, reduces surface bacteria by > 99.97%
  • RoHS Compliant (Non-Halogenated)
  • Independently tested and Certified to JIS Z2801 standards
  • Resistant to High Pressure Hose-down applications
  • Tongue & Groove Environmental Sealing
  • Keyed Body and Cover for Alignment
  • NEMA Type 4, 4x, 6, 6P and IP67 Protection
  • Steriguard™ Anti-microbial Wiring Devices are ideal for a wide range of applications including food and beverage preparation, procession, & packaging; agriculture, pharmaceutical, and health care.
