Product image for Appleton Group ENR5201 U-Line 20 Amp 125 Volt Receptacle Assembly
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Appleton Group ENR5201 U-Line 20 Amp 125 Volt Receptacle Assembly

Manufacturer: Appleton Electric | Catalog # ENR5201 | Echo Electric Part # 176271
$690.45/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet Product Catalog Page
U-Line™ Contender™ Factory Sealed 20 Amp Plugs and Receptacles feature a dead front design making them ideal for use with electrical equipment in hazardous locations. The neoprene gasket in the throat of the receptacle seals against the plug or the spring-loaded cover to seal out water, dust and corrosive compounds. Although U-Line plugs can be used with ordinary receptacles, U-Line receptacles are designed so that they can't be energized by an ordinary plug.

Technical Information

Amperage
20 Amp
Applications
For ECP Mating Plugs
Material
Copper-free Aluminum Cover and Malleable Iron Box
Mounting Type
Box
Number of Poles
3 Pole
Number of Wires
2 Wire
Standard
Class E Requirements For Channel,Component Level Performance Per TIA,EIA-568-B.2-1 And ISO,Extreme 6+ System Components Meet Or Exceed The Category 6,IEC 11801-B. Components Certified Per UL And CUL Listed, NOM And ACA Requirements
Type
Replacement Receptacle Cover Assembly
Voltage
125 Volt

Manufacturer Information

Brand
Appleton
Sub Brand
Contender™, U-Line™

General Product Info

12-Digit UPC
781381815024
GTiN
00781381815024
Product UPC
78138181502
Features
  • Dead front design: receptacle is not energized until plug is fully inserted and switch is engaged
  • ECP plug fits any standard non-explosionproof receptacle (NEMA 5-20R, or 6-20R) as well as U-Line explosionproof receptacles
  • Insulators provide superior dielectric and mechanical strength and lowest arc tracking
  • Ground fault circuit interrupting cover and receptacle combinations available
  • Covers are UL Listed when used with Contender™ Series mounting boxes, and UL Classified when used with Crouse-Hinds™ EDS™ series mounting boxes
  • Intermatable with competitor's plugs of like configurations
