Product image for Thomas & Betts 10RC-14FX 1/4 Inch Bolt Hole 12-10 AWG Wire Range Yellow Expanded Insulated Vinyl Fork Terminal
Image thumbnail 0
Image thumbnail 1
Email

Thomas & Betts 10RC-14FX 1/4 Inch Bolt Hole 12-10 AWG Wire Range Yellow Expanded Insulated Vinyl Fork Terminal

Manufacturer: Thomas & Betts Co | Catalog # 10RC-14FX | Echo Electric Part # 180137
$301.47/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Product Spec Sheet Product Catalog Page
Expanded Vinyl-Insulated Fork Terminal, Length 1.17 Inches, Width .50 Inches, Maximum Insulation .250, Bolt Hole 1/4 Inch, Wire Range #12-#10 AWG, Color Yellow, Copper, Tin Plated

Technical Information

Conductor Size
12-10 AWG
Flamability Class
Rated V-0 Per UL94
Insulation Material
PVC
Insulation Type
Expanded Insulated Vinyl
Material
Copper
Standard
CSA,E2186,UL
Stud Size
1/4 in
Temperature Rating
105 degrees C
Terminal Type
RC
Type
Short Sleeve
Voltage
600 Volt
Wire Size
12-10 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210800486
Color
Yellow
Finish
Tin Plated
GTiN
05414363935759
Product UPC
78621080048
Used With
Round Conductors

Dimensions

Height
3 Inch
Thickness
.04 in
Width
1.3 in
Features
  • Fork teminals allow easy installation since the mounting screw does not have to be completely removed. These terminals have expanded insulation support which means a wider wire entry to accommodate heavy wall insulation.
Certifications
  • CSA
  • UL
