Klein VDV526-200 LAN Scout® Jr. 2 Cable Tester

Manufacturer: Klein Tool | Catalog # VDV526-200 | Echo Electric Part # 205573
$59.97/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 13 to 21 days
Product Spec Sheet Safety Data Sheet
The LAN Scout® Jr. 2 Cable Tester tests installed or loose data (CAT 5e, CAT 6/6A) cables terminated with RJ45 connectors. It also, tones cables with multiple tone frequencies. The larger display is backlit for easier reading in low lit areas. This model uses 2 x AAA batteries (included). Three buttons provide an intuitive user interface.

Technical Information

Applications
For Cable Testing
Battery Life
Active: 80 Hours; Standby: 3 Years
Cable Type
Shielded or Unshielded; Cat7, Cat6/6A, Cat5E, Cat3
Connector Type
Cat7, Cat6/6A, Cat5E, Cat3
Display Type
LCD
Material
Plastic
Type
DATA, Voice, LAN

Manufacturer Information

Brand
Klein Tools, Inc.

General Product Info

12-Digit UPC
092644583544
GTiN
00092644583544
Product UPC
09264458354
Weight
0.272 lb

Dimensions

Depth
5.229 Inch
Height
1 Inch
Overall Length
5 in
Width
2.5 in

Certifications and Compliance

Country of Origin
China
Warnings
  • Always wear approved eye protection.
  • Read all safety Information before using the product.
  • Carefully read all instructions.
  • Designed for use on unpowered/dark cable systems.
  • Do NOT connect to live AC power.
  • For indoor use only.
Features
  • Cable tester for data (RJ45) terminated cables and patch cords
  • Large backlit LCD for low lit areas displays pin to pin wiremap results
  • Test for Open, Short, Miswire or Split-Pair faults, Cross-over and Shield
  • Intuitive user interface features three buttons with simple, easy-to-identify test responses
  • Tone on single wire, wire pair or all 8 conductor wires
  • Multiple style tone generator (solid / warble); requires probe Cat. No. VDV500-123 (sold separately)
  • Auto Power-Off feature; 10-minutes in test mode, 60-minutes in tone mode
  • Soft, slip-resistant, rugged overmold for easy gripping and durability
  • Replaceable 2 x AAA batteries (included)
  • Replaceable self-storing remote (included)
  • Replacement remote available; sold separately (Cat. No. VDV999-200)
  • Backlit LCD
