Square D JJL36250M75 600 Volt 250 Amp Motor Circuit Protector

Manufacturer: Square-D / Schneider | Catalog # JJL36250M75 | Echo Electric Part # 210169
$2,365.72/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2
PowerPacT J-Frame motor circuit protectors (MCP) are instantaneous-trip circuit breakers designed to offer short circuit protection for motors. The unique design of the PowerPacT MCPs accommodates transient motor inrush current without nuisance tripping. These motor protectors accept the same accessories and terminals as the PowerPacT J circuit breakers. This unit has lugs on both the line and load side. This PowerPacT J, 250A, 3 pole, motor protector has a breaking capacity of 25kA at 600VAC. The breaker has a continuous current rating of 80%. PowerPacT J motor circuit protectors comply to UL, CSA, and IEC standards and are CE marked.

Technical Information

Amperage
250 Amp
Applications
DESIGNED TO OFFER SHORT CIRCUIT PROTECTION
Control Type
Toggle
Frame
J
Interrupt Rating
25, 65, 100 kAIC
Line Rated Current
250-250 A
Mounting Type
Unit Mount
Net Weight
2.4 kg
Number of Poles
3 Pole
Operating Temperature
40 Adegrees C
Standard
CSA,IEC 60947-2,NEMA,NOM-003-SCFI-2000,UL
Storage Temperature
-50-85 degrees C
Strip Length
25 mm
TC Connection
AWG 3/0...350 KCMIL ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE
Trip Point
2500-2500 A
Trip Range
6842500 A
Trip Type
MOTOR CIRCUIT PROTECTOR
Type
Motor Circuit Protector
Voltage
600 Volt

Manufacturer Information

Brand
Square D
Sub Brand
POWERPACT

General Product Info

12-Digit UPC
785901541134
GTiN
00785901541134
Product UPC
78590154113
Weight
2.4 kg

Dimensions

Depth
86 mm
Height
191 mm
Length
25 mm
Warranty Length
18 mth
Width
104 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CSA,NOM,UL
Country of Origin
Mexico
Prop 65
  • WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
