Square D BMXXBP1200 12-Slot PLC Backplane

Manufacturer: Square-D / Schneider | Catalog # BMXXBP1200 | Echo Electric Part # 214762
$561.11/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
CA Prop65 Warning CA Prop65 Warning Product Spec Sheet Product Catalog Page CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
This 12 slots X-bus rack is part of the Modicon X80 modules. Number of slots comprises processor, I/O, communication and application-specific modules (excluding power supply module). It can be mounted on DIN rail and its weight is 1.270kg.

Technical Information

Applications
BMXCPS POWER SUPPLY-BMXP34 PROCESSOR-I/O MODULE-SPECIFIC APPLICATION MODULE,RACK
Enclosure
IP20
Net Weight
1.27 kg
Standard
CSA C22.2 No 61010-2-201,EN/IEC 61000-6-5, Interface Type 1 And Type 2,EN/IEC 61010-2-201,EN/IEC 61131-2,EN/IEC 61850-3, Location G,IACS E10,UL 61010-2-201
Temperature Rating
0-60 A?degrees C
Type
Rack
Wattage
0.74 Watt

Manufacturer Information

Brand
Schneider Electric
Sub Brand
MODICON M340

General Product Info

12-Digit UPC
595863909022
GTiN
03595863909029
Product UPC
78590147696
Weight
1.27 kg

Dimensions

Depth
19 mm
Height
103.7 mm
Warranty Length
18 mth
Width
503.2 mm

Certifications and Compliance

CA Prop65 Warning
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Certifications
CE,CSA,EAC,Merchant Navy,RCM,UKCA,UL
Country of Origin
France
Prop 65
  • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
