Product image for Panduit UTP28X10YL Cat 6A 28 AWG UTP Copper Patch Cord, 10 ft, Yellow
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Panduit UTP28X10YL Cat 6A 28 AWG UTP Copper Patch Cord, 10 ft, Yellow

Manufacturer: Panduit Corp | Catalog # UTP28X10YL | Echo Electric Part # 224986
$36.43/ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 8 to 12 days
Buy American Compliant Buy American Compliant Product Spec Sheet Installation / Instruction Manual
The TX6A-28™ Cat 6A UTP Patch Cord is constructed of 28 AWG, unshielded, twisted pair, solid, CM/LSZH cable with enhanced performance modular plugs. The use of 28 AWG cable ensures that this patch cord has a small diameter, making it easy to install and work with. The patented tangle free latch prevents snags and provides easy release saving time on frequent moves, adds, and changes. The patch cord is 10 feet in length, 0.185 inches (4.7mm) nominal in diameter, and yellow.

Technical Information

Applications
(1) 10GBASE-T Ethernet (2) Data center I/O Consolidation (3) Data center server virtualization (4) Backbone aggregation (5) Parallel processing and high speed computing
Boot Color
Clear
Cable Type
28 AWG F/UTP
Conductor Material
Copper
Conductor Type
Solid
Connector Type
Modular Plug
Material
Copper
Max Operating Temperature
140 degrees F
Min Operating Temperature
14 degrees F
Performance Level
Category 6A
Plug Type
Modular Plug with Bulkhead and Dust Cap
Temperature Rating
140 degrees F
Type
Category 6A
Wire Size
28 AWG

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
PanNet

General Product Info

12-Digit UPC
074983030163
Color
Yellow
GTiN
00074983030163
Jacket Material
High-Density Polyethylene
Product UPC
07498303016

Dimensions

Cable Length
10 ft
Length
10 Inch
Outside Diameter
4.7 mm
Overall Length
10 ft

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
CN,CR,MX,RO
Standards and Certifications
  • Standards Met: Exceeds all ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA standards for all frequencies from 1 to 500 MHz; Meets ANSI/TIA-1096-A (formerly FCC Part 68); IEC 60603-7; UL 1863 and CAN/CSA-C22.2 (UL File E129886), RoHS Compliant, Supports IEEE 802.3af/802.3at and 802.3bt type 3 and type 4 PoE applications; RoHS Compliant; wired to be compatible with both T568A and T568B wiring schemes.
